Takotsubo Cardiomyopathy

Welcome to PT 635 Pathophysiology of Complex Patient Problems This is a wiki created by and for the students in the School of Physical Therapy at Bellarmine University in Louisville KY. Please do not edit unless you are involved in this project, but please come back in the near future to check out new information!!

Definition/Description

Takotsubo cardiomyopathy occurs when there is an abnormal contraction of the transient left ventricle, creating a balloon shape appearance initially during systole. The Japanese first described the heart condition around 1991. The shape of the heart resembles a Japanese octopus trapping pot with a rounded bottom and narrow neck; hence the name tako-tsubo.[1]

Japanese pot 2.jpg








(Obtained permision from author to use photo)

Image depicting resemblance between heart during contraction phase in patient with TC (on left) and Japanese takotsubo (on right)[2]


Typically an intense emotional stress can trigger this type of event. High levels of catecholamines are present in these patients and can cause the heart to be stunned temporarily. This is a reversible cardiomyopathy and clinically presents as a myocardial infarction. Individuals that experience this may or may not have a cardiovascular disease.
Other names include:

  • Broken heart syndrome
  • Ampulla cardiomyopathy
  • Stress cardiomyopathy
  • Apical ballooning syndrome (ABS)
  • Acute left ventricular ballooning[1]

Prevalence

Takotsubo cardiomyopathy is a very rare condition and has to be differentiated from myocardial infarct. The incidence of takotsubo cardiomyopathy is 1-2% in patients diagnosed with MI. These individuals are usually postmenopausal females (90%). The average age is 62-75 years old. There are approximately 7,000-14,000 cases of takotsubo cardiomyopathy in the U.S.[3]

Characteristics/Clinical Presentation


Usually takotsubo cadiomyopathy is triggered by emotional stress, physical stress, non-cardiac surgery or procedure (refer to table). The onset is insidious and presents with chest pain at rest.

Table I. Stressors reported to trigger ABS[3]
Emotional stress
Death or severe illness or injury of a family member, friend, or pet
Receiving bad news—diagnosis of a major illness, daughter's divorce, spouse leaving for war
Severe argument
Public speaking
Involvement with legal proceedings
Financial loss—business, gambling
Car accident
Surprise party
Move to a new residence
Physical stress
Non-cardiac surgery or procedure—cholecystectomy, hysterectomy
Severe illness—asthma or chronic obstructive airway exacerbation, connective tissue disorders, acute cholecystitis, pseudomembranous colitis
Severe pain—fracture, renal colic, pneumothorax, pulmonary embolism
Recovering from general anesthesia
Cocaine use
Opiate withdrawal
Stress test—dobutamine stress echo, exercise sestamibi
Thyrotoxicosis


 Signs and Symptoms of Takotsubo include:[3][4]

  • Chest pain
  • Dyspnea
  • Hypotension
  • Syncope
  • Mild to moderate HF
  • Pulmonary edema
  • Lab Changes
  • Modest increase in troponin T levels
  • Increase in creatine phosphokinase (CPK)
  • Elevation in pBNP
  • High levels of serum catecholamines


The most common signs and symptoms are chest pain and dyspnea; resembling a myocardial infarction.

Associated Co-morbidities

Research has not shown any comorbidities linked with TC.

Medications

There have not been any randomized control trials done to assess medical therapies used for TC. During left ventricular dysfunction, angiotensin-converting enzyme (ACE) inhibitors or angiotensin receptor blockers are given. Beta-blockers are also given for long-term treatment to maybe reduce the risk of another episode.

Some medications include:[5]

  • Salicylate- inhibit platelet aggregation
  • Antianginal Agents- reduce blood pressure
  • Anagesics- pain control
  • Anticoagulants- inhibit thrombogenesis
  • Low Molecular Weight Heparins- inhibit thrombogenesis
  • Antiarrhythmic Agents- reduce episodes of chest pain.
  • Platelet Aggregation Inhibitors- reduce platelet aggregation
  • Loop Diuretics- reduce blood pressure
  • Thiazide Diuretics- reduce blood pressure
  • Antihypertensive Agents- reduce blood pressure
  • Antiplatelet Agents- inhibit platelet aggregation
  • ACE Inhibitors- control blood pressure
  • Beta-adrenergic Blockers- reduce blood pressure
  • Calcium Channel Blockers- improve oxygen delivery to myocardial tissue

Diagnostic Tests/Lab Tests/Lab Values

Diagnostic tests used for TC include lab values, echocardiography, cardiac angiography, and electrocardiography.

Lab Values[5]
Troponin T level:

  • Mean value of healthy individuals = 0.49 ng/mL,
  • Mean peak value of patients with TC = 0.64 ng/mL

Troponin I level:

  • Mean value of healthy individuals = 4.2 ng/mL
  • Mean peak value of patients with TC = 8.6 ng/mL

Brain natriuretic peptide level is elevated
Catecholamines are elevated in the acute phase

Echocardiography[5]
An echocardiography is used when diagnosing wall-motion abnormalities. The heart will show hypokinesis or akinesis of the middle and apical segment of the left ventricle if the diagnosis is TC.

Cardiac Angiography[5]
The test will show normal coronary arteries in patients with TC.

Electrocardiography (EKG) Changes[4]

Generally, patients could have 4 different EKG changes:

  • ST-segment elevation
  • T-wave inversion
  • Abnormal Q waves
  • QT segment prolongation


In a study conducted by Mitsuma et al, they showed that EKG changes could occur in phases:

  1. ST-segment elevation (immediately)
  2. T-wave inversion (days 1-3)
  3. Improvement in T-wave inversion (days 2-6)
  4. Deeper T-wave inversion

Diagnostic Criteria[4]
Must have all 4 criteria to be diagnosed with ABS
• Transient hypokinesis, akinesis, or dyskinesis of the LV midsegments
• Absence of obstructive coronary artery or angiographic evidence of acute plaque rupture
• New EKG abnormalities or elevated cardiac troponin
• Absence of recent head trauma, intracranial bleeding, pheochromocytoma, myocarditis, and hypertrophic cardiomyopathy

Etiology/Causes

Research has shown three possible causes of takotsubo cardiomyopathy: increased levels of catecholamines, left ventricular outflow tract (LVOT) obstruction, and microcirculation dysfunction.

TC Heart.jpg

[4] (Pending permission from author)

  1. Catecholamines (norepinephrine, epinephrine, and dopamine): In individuals with suspected TC, catecholamines are 7 to 34 times higher than the values of normal individuals.  The catecholamine levels are also 2 to 3 times greater than with individuals diagnosed with a myocardial infarction.  These levels stay elevated for 7 to 9 days following the episode.[6] TC can develop due to high doses of epinephrine.  There are also more catecholamine-sensitive receptors in the apex of the heart, making it more sensitive to increased levels.[7]
  2. LVOT obstruction: It could be linked to the increased catecholamine levels and occurs in approximately 25% of patients with TC.[8] Other factors that lead to this obstruction are mid-ventricular septal thickening (common in elderly women), increased ventricle wall stress, increased filling pressure, and decreased systemic blood pressure.[9]  This obstruction can result in myocardial ischemia and "stunning" of the heart due to the increased oxygen demand and decreased coronary artery perfusion pressure.
  3. Microcirculation dysfunction[8][9]: It can involve many vessels and occurs in the majority of patients who present with TC.  The dysfunction can either be vasospasms or decreased coronary artery blood flow without any indication of atherosclerosis.  The vasospasms could possibly be due to increased stimulation of the B1 receptors.  Studies attempted to provoke vasospasms using a chemical and among the studies, only 0-43% patients experienced the effect; therefore, microcirculation dysfunction is a questionable cause of TC.

Systemic Involvement

There are a number of possible complications in patients who present with takotsubo cardiomyopathy. Left-sided congestive heart failure with pulmonary edema, cardiogenic shock, ventricular fibrillation, left ventricular thrombus formation, and left ventricular free wall rupture are all possibilities. Death is included in this list; however, the mortality rate is only 0-8%, and generally less than 2%.[10]

Medical Management (current best evidence)

The optimal management of TC has not been established. Current medical management for TC has included medication. Since the disease presents similarly to myocardial ischemia it is important to treat the patient initially with EKG monitoring, aspirin, heparin, and beta-blockers.[3] The medications used are described earlier in the medication section. The main focus is “reducing pain, alleviating anxiety, patient monitoring, and prevention of complications,” and risk of a second event.[3]  The patients are monitored to ensure that the disease resolves. After discharge the patient is instructed to follow up with a primary care physician to review medications (chronic beta blockers) and health status.[1]

Physical Therapy Management (current best evidence)

Preferred Practice Pattern:

Pattern 6D: Impaired Aerobic Capacity/Endurance Associated With Cardiovascular Pump Dysfunction or Failure


Studies have not investigated the direct effects of physical therapy on the status of patients with TC.  Research has demonstrated favorable effects of cardiac rehabilitation on other cardiovascular conditions, including myocardial infarction.  A systematic review and meta-analysis examining myocardial infarction by Lawler et al found that "patients randomized to exercise-based cardiac rehabilitation had a lower risk of reinfarction and cardiac mortality...Exercise-based CR had favorable effects on cardiovascular risk factors, including smoking, blood pressure, body weight, and lipid profile."[11]

One study by Yu et al in 2007 compared a relaxation training group, exercise training group, and control group[12]. Both the relaxation and exercise groups showed significant improvement in psychological and various disease-specific quality of life outcomes compared to the control group. Relaxation training proved better to decrease psychological distress, while exercise training controlled fatigue symptoms.

A later study by Yu et al in 2010 placed 59 of the 121 Chinese patients with chronic heart failure into a relaxation-training program and compared them to a control group[13]. The relaxation training included "two relaxation training sessions, one skill revision workshop, twice daily relaxation self-practice, and biweekly telephone follow-up." The program had significantly improved the psychological and social health-related quality of life compared to the remaining patients in the control group.

Differential Diagnosis

The following are possible diagnoses that present similarly to TC[5]:

• Esophageal spasm
• Gastroesophageal reflux disease
• Myocardial infarction
• Myocardial ischemia
• Myocarditis
• Acute pericarditis
• Pneumothorax
• Cardiogenic pulmonary edema
• Pulmonary embolism
• Unstable angina
• Acute Coronary Syndromes
• Angina Pectoris
• Aortic Dissection
• Boerhaave Syndrome
• Cardiac Tamponade
• Cardiogenic Shock
• Cardiomyopathy, Cocaine
• Cardiomyopathy, Dilated
• Cardiomyopathy, Hypertrophic
• Coronary Artery Vasospasm

Case Reports/ Case Studies

Metzl MD, Altman EJ, Spevack DM, Doddamani S, Travin MI, Ostfeld RJ. A case of takotsubo cardiomyopathy mimicking an acute coronary syndrome. Nature Clin Prac: Cardiovasc Med. 2006;3(1):53-6.

Nykamp D, Titak JA. Takotsubo cardiomyopathy, or broken-heart syndrome. Ann Pharmacother. 2010;44:590-3.

Obunai K, Misra D, Van Tosh A, Bergmann SR. Metabolic evidence of myocardial stunning in takotsubo cardiomyopathy: a positron emission tomography study. Jour Nuc Cardiol. 2005;12(6):742-4.

Resources

American Heart Association HeartHub for Patients

http://www.hearthub.org/

Recent Related Research (from Pubmed)

References

see adding references tutorial.

  1. 1.0 1.1 1.2 Nussinovitch U, Goitein O, Nussinovitch N. Distinguishing a Heart Attack From the “Broken Heart Syndrome” (Takotsubo Cardiomyopathy). Journal of Cardiovascular Nursing. 2011; 1-6.
  2. Sharkey SW, Lesser JR, Maron BJ. Takotsubo (stress) cardiomyopathy. Circulation. 2011;124:e460-e462.
  3. 3.0 3.1 3.2 3.3 3.4 Prasad A. Lerman A, Rihal CS. Apical ballooning syndrome (Tako-tsubo or stress cardiomyopathy): A mimic of acute myocardial infarction. American Heart Journal. 2008; 155 (3):408-417.
  4. 4.0 4.1 4.2 4.3 Coons JC, Barnes M, Kusick K. Takotsubo cardiomyopathy. Am J Health-Syst Pharm. 2009; 66: 562-66.
  5. 5.0 5.1 5.2 5.3 5.4 Tomich EB, Luerssen E, Kang CS. Takotsubo Cardiomyopathy. Medscape Website. http://emedicine.medscape.com/article/1513631-overview. Published 2012. Accessed March 20, 2014.
  6. Wittstein IS, Tiemann DR, Lima JAC. Neurohormonal features of myocardial stunning due to emotional stress. N Engl J Med. 2005;352:539-48.
  7. Seaglove BA, Tiyyagura S, Fuster V. Takotsubo Cardiomyopathy. J Gen Intern Med. 2008;23(11):1904-8.
  8. 8.0 8.1 Antionopoulos A, Kyriacou C. Apical ballooning syndrome or Takotsubo cardiomyopathy: A new challenge in acute cardiac care. Cardiol J. 2008;15:572-577.
  9. 9.0 9.1 Nef HM, Mollmann H, Akashi YJ. Mechanisms of Stress (Takotsubo) cardiomyopathy. Cardiol J. 2010;7:187-193.
  10. Barker S, Solomon H, Bergin JD. Electrocardiographic ST-segment elevation: Takotsubo cardiomyopathy versus ST-segment elevation myocardial infarction – A case series. Amer J of Emer Med. 2009; 27: 220-226.
  11. Lawler PR, Fillon KB, Eisenberg MJ. Efficacy of exercise-based cardiac rehabilitation post–myocardial infarction: A systematic review and meta-analysis of randomized controlled trials. Amer Heart J. 2011;162(4):571-84.
  12. Yu DSF, Lee DTF, Woo JB, Hui EC. Non-pharmacological interventions in older people with heart failure: effects of exercise training and relaxation therapy. Gerontology. 2007;53(2):74–81
  13. Yu DSF, Lee DTF, Woo J. Improving health-related quality of life of patients with chronic heart failure: effects of relaxation therapy. Journal of Advanced Nursing. 2010;66(2):392–403
