Calcaneal Fractures

Original Editor

Top Contributors -     Hajar Abdelhadji, Roxann Musimu , Dylan Van Calck

Definition / Description

A calcaneus fracture is a heel bone fracture.The calcaneus, the largest tarsal bone, is specifically designed to support the body and endure a great degree of force. It is situated at the lower and back part of the foot, forming the heel.[1]
Together with the talus, the calcaneus forms the subtalar joint. This joint allows inversion and eversion of the foot. The midtarsal joint is comprised of two joints: The talocalcaneonavicalar and the calcaneocuboid joint. [2]

The calcaneus has four important functions:
1. Acts as a foundation and support for the body’s weight
2. Supports the lateral column of the foot and acts as the main articulation for inversion / eversion
3. Acts as a lever arm for the gastrocnemius muscle complex
4. Makes normal walking possible

Clinically Relevant Anatomy

A sound understanding of the anatomy of the calcaneus is essential in determining the patterns of injury and treatment goals and options.
The bony architecture of the calcaneus is that of an irregularly shaped rectangle with four facets, one of which articulates anteriorly with the cuboid bone and three of which (the anterior, middle, and posterior facets) articulate superiorly with the talus.[3]


The superior surfaces articulate with the talus

  • Posterior facet : Separated from the middle and anterior facets by a groove that runs posteromedially, know as the calacaneal sulcus. The canal formed between the calcanealsulcus and talus is called the sinus tarsi.
  • Middle calcaneal facet : Supported by the sustenaculum tali and articulates with the middle facet of the talus.
  • Anterior calcaneal facet :articulates with the anterior talar facet and is supported by the calcaneal beak.

The triangular anterior surface of the calcaneus articulates with the cuboid
The lateral surfaces

  • The lateral surface is flat and subcutaneous, with a central peroneal tubercle for the attachment of the calcaneofibular ligament centrally. The lateral talocalcaneal ligament attaches antero-superiorly to the peroneal tubercle.

These anatomic landmarks are important because fractures associated with these areas may cause tendon injury[4]



Epidemiology/Ethiology

Calcaneal fractures correspond to approximately 1% to 2% of all the fractures of the human body and constitute nearly 60% of tarsal bones fractures. They generally follow high-energy axial traumas, such as fall from height or motor accidents.
According to the current literature, 60% to 75% of these fractures are considered to be displaced and intra-articular, which evidences the difficulty of the treatment. They can cause great disability due to pain and chronic stiffness, in addition to hindfoot deformities. These fractures are characterized clinically by poor functional results due to their complexity.
Approximately 80% to 90% of the calcaneal fractures happen in males between 21 and 40 years, mostly in industrial workers. Several authors have reported that the rehabilitation of these fractures can take from nine months to several years, which implicates great economic burden on society.
Since the early 1980s, the treatment of choice for displaced and intra-articular calcaneal fractures was open reduction with internal fixation; however, soft tissue complications, such as surgical dehiscence and infection, can occur in up to 30% of the patients.
In an attempt to reduce complication rates, new surgical techniques emerged, such as minimally invasive incision and percutaneous fixation, which cause less injury to the tissues and reduce the incidence of soft tissue complications.
Despite the modern surgical techniques and the considerable number of studies in the literature, calcaneal fractures and their best treatment method remain an enigma for orthopedic surgeons. [5][6]



Mechanism of Injury / Pathological Process

Calcaneal fractures occur rarely. They only consist of 1,2% of all relatively rare injuries. The calcaneus is the most frequently fractured tarsal bone. Calcaneal fractures are mostly the result of a traumatic incident and high impact situation. The greater part of fractures (71,5%)[7] are sustained in falls from a height from usually 6 feet or more, a motor vehicle accident. The small amount of 18.8% of fractures occurred in the workplace. Calcaneal fractures can also occur with less severe accidents like an ankle sprain or a stress fracture.

Mostly, the injuries occur in isolation. Most seen concomitant injuries were lower limb (13.2%) or spinal injuries (6.3%).

Calcaneal fractures can be extra-articular or intra-articular. The extra-articular fractures represent 60% of the calcaneal fractures in children and their incidence has been reported to be 25-40% of adult calcaneal fractures. They don’t involvde the joint. according to the mechanism of injury, they can be classified as compression or avulsion fractures. They can also be categorized according to their location in the calcaneus. (Mandeep et al.)
Intra-articular fractures do include the joint and have a lower prognosis and are more difficult to recover from. This type of fractures can be categorized in four different types according to Sanders (Mandeep et al.). With type II being non-displaced intra-articular fractures. Type II being two-part fractures which can be divided in Type IIa, IIb and IIc. Type III fractures which can also be divided into IIIa, IIIb and IIIc and usually have a depressed articular segment. Type IIII represents a four-part or very comminuted fracture (Mandeep et al. Level 2a)[8]

Characteristics / Clinical Presentation

  • There are certain characteristics of a calcaneal fracture:
  • Sudden pain in the heel, most importantly pressure pain.
  • Swelling in the heel area
  • Bruising of the heel and ankle
  • Generalized pain in the heel area that usually develops slowly (over several days to weeks): typically for stress fractures
  • Edema
  • A hematoma or pattern of ecchymosis extending distally to the sole of the foot.
  • Deformity of the heel or plantar arch: Secondary to the displacement of the lateral calcaneal border outward, there is a possible widening or broadening of the heel.
  • Inability or difficulty to bear weight on affected side
  • Limited or absent inversion / eversion of the foot
  • Decreased Böhler or “tuber-joint” angle
  • CT scan: Diverse views, both axial and coronal views can classify the degree of injury to the posterior facet and lateral calcaneal wall.
  • X-rays or Radiographs:

-Axial x-ray: Determines primary fracture line and displays the body, tuberosity, middle and posterior facets
-Lateral x-ray: Determines Böhler angle [9]
-Oblique / Broden’s view: Determines the degree of displacement of the primary fracture line

  • Heel tenderness
  • Difficulty walking:

-Inability to walk
-Inability to move the foot

Differential Diagnosis

  • Heel pain
  • Baxter's nerve entrapment: An entrapment of the recurrent branch of the posterior tibial nerve
  • Calcaneal spurs[10]
  • Plantar fasciitis: Plantar fascial pain is specific to the bottom of the heel. An MRI can be used to differentiate a calcaneal fracture from plantar fascitis.[11]
  • Retrocalcaneal bursitis: This is the formation and inflammation of a bursa at the back of the heel between the heel bone and achilles tendon. Also called Albert's Disease.
  • Rheumatoid Arthritis
  • Septic Arthritis
  • Tarsal Tunnel Syndrome: The pain of this syndrome doesn’t decrease with rest. Other symptoms are numbness or tingling of the toes.[12]
  • Ankle instability[13]

Diagnostic Procedures

  • Pain - Most importantly pressure pain, or pain elicited when providing pressure to the calcaneus by holding the heel of the patient’s foot and gently squeezing [14]
  • Edema
  • Ecchymosis - A hematoma or pattern of ecchymosis extending distally to the sole of the foot is specific for calcaneal fractures and is known as the Mondor sign
  • Deformity of the heel or plantar arch - Widening or broadening of the heel is seen secondary to the displacement of the lateral calcaneal border outward and accompanying edema
  • Inability to or difficulty weight-bearing on affected side [15]
  • Limited or absent inversion/eversion of the foot [16]
  • Decreased Bohler or “tuber-joint” angle - In normal anatomical alignment an angle of 25-40 degrees exists between the upper border of the calcaneal tuberosity and a line connecting the anterior and posterior articulating surfaces. With calcaneal fractures,this angle becomes smaller, straighter, and can even reverse.
  • CT scan (both axial and coronal views) to classify the degree of injury to the posterior facet and lateral calcaneal wall [17]
  • X-rays or Radiographs:
  1.  Axial - Determines primary fracture line and displays the body, tuberosity, middle and posterior facets
  2. Lateral - Determines Bohler angle
  3. Oblique/Broden’s view - Displays the degree of displacement of the primary fracture line.

Outcome Measures

http://www.physio-pedia.com/Lower_Extremity_Functional_Scale_(LEFS)

http://www.physio-pedia.com/Foot_and_Ankle_Ability_Measure


The objective of the Lower Extremity Functional Scale (LEFS) is to measure "patients' initial function, ongoing progress, and outcome" for a wide range of lower-extremity conditions.

he Foot and Ankle Ability Measure (FAAM) is a self-report outcome instrument developed to assess physical function for individuals with foot and ankle related impairments. This self-report outcome instrument is available in English, German, French and Persian. The Foot and Ankle Ability Measure is a 29-item questionnaire divided into two subscales: the Foot and Ankle Ability Measure, 21-item Activities of Daily Living Subscale and the Foot and Ankle Ability Measure, 8-item Sports Subscale. The Sports subscale assesses more difficult tasks that are essential to sport, it is a population-specific subscale designed for athletes.

Examination

To diagnose and evaluate a calcaneal fracture, the foot and ankle surgeon will ask questions about how the injury occurred, examine the affected foot and ankle and order x-rays. In addition, advanced imaging tests such as CT-scans are commonly required after a fracture. These provide more detailed, cross-sectional images of your foot.[18]
During the examination, a lot of different symptoms can be seen. The most obvious ones are pain, bruising, swelling, heel deformity and an inability of the patient to put weight on the heel or walk. Still, medical imaging should be the main way to diagnose a calcaneal fracture.[19]
The physiotherapist will examine the ankle to see if the skin was damaged or punctured from the injury. He will check for a pulse to see if there is a sufficient blood supply at the injured area. Also he should check if the patient can move his toes and feel at the bottom of his foot to determine if there are any other injuries that occurred with the calcaneal fracture. Other techniques like squeezing the hell causes elicits pain over the calcaneal protuberances. A thorough neurovascular examination is also essential. level 2b[20]

Questionnaires :

One of them most used outcome measures for patients is the VAS-scale. This can be used to determine how the patient lives with his injury. We can measure how big the pain is before and after treatment. This can be useful to determine if the therapy has been successful or not.[21]


Medical management / Interventions

Treatment of calcaneal fractures depends on the type of fracture and the extent of the injury.

There is no universal treatment or surgical approach to all displaced intra-articular calcaneal fractures. The choice of treatment must be based on the characteristics of the patient and on the type of fracture.

File:FCK MWTemplate

Operative care[22]

For the majority of patients, surgery is the correct form of treatment. The goal of surgery is to restore the correct size and structure of the heel. Intra-articular fractures are often treated operatively. This is possible by performing an open reduction and internal fixation of the fracture. These procedures are performed through an incision on the outside of the heel. The calcaneus is put together and held in place with a metal plate and multiple screws. This procedure decreases the possibility of developing arthritis and maximizes the potential for inversion and eversion of the foot.
Extra-articular fractures are generally treated conservatively.

If you want more information about the types of surgeries you can consult the article in references. (Comparative study on three surgical techniques for intra-articular calcaneal fractures: open reduction with internal fixation using a plate, external fixation and minimally invasive surgery.) Level 1b [23] [24]



Non-operative care

Nonoperative management is preferable when there is no impingement of the peroneal tendons and the fracture segments are not displaced (or are displaced less than 2 mm). Nonoperative care is also recommended when, despite the presence of a fracture, proper weight-bearing alignment has been adequately maintained and articulating surfaces are not disturbed. Extra-articular fractures are generally treated conservatively. Patients who are over the age of 50 years old or who have pre-existing health conditions, such as diabetes or peripheral vascular disease, are also commonly treated using nonoperative techniques. Patients receiving nonoperative management. Level 1A [25][26]

R.I.C.E.:

  • Rest: The affected foot must rest and the patient is not allowed to use the foot. This is to allow the fracture to heal.
  • Ice: Several times a day the patient has an ice treatment to reduce inflammation, swelling and pain.
  • Compression: Bandage / Compression stocking
  • Elevation: The initial management is to reduce the swelling with rest in bed with the foot slightly above heart level.

Immobilisation:
Partial or complete immobilisation is used if the fracture has not displaced the bone. Usually a cast is used to keep the fractured bone from moving. In the cast, the ankle is in neutral position and sometimes in slight eversion.
To avoid weight bearing, crutches may be needed.

Physical Therapy Management

After the surgery, active range of motion exercises may be practiced with small amounts of movement for all joints of the foot and ankle. These exercises are used to maintain and regain the ankle joint movement. When needed for the involved lower extremity, the patient may continue with elevation, icing and compression. During the therapy, the patient will progress to gradual weight bearing. Patients may find this very difficult and painful. The physiotherapist conducts joint mobilisation to all hypomobile joints.
During the treatment, progressive resisted strengthening of the gastrocnemius muscles is done by weighted exercises, toe-walking, ascending and descending stairs and plyometric exercises. When the fracture is healed, the physiotherapist will progress the weight bearing in more stressful situations. This therapy consists of gait instruction and balance practice on different surfaces.

Acute stage

Immobilization. A cast, splint, or brace will hold the bones in your foot in proper position while they heal. You may have to wear a cast for 6 to 8 weeks — or possibly longer. During this time, you will not be able to put any weight on your foot until the bone is completely healed. Level 2a [27]

Before surgery

Initial stability is essential for open reduction internal fixation of intraarticular calcaneal fractures.

Preoperative revalidation consist on:
• Immediate elevation of the affected foot to reduce swelling
• Compression such as foot pump, intermittent compression devices or compression wraps.
• ICE
• Instructions for using wheelchair, bed transfers, or crutches. level 2a [28][29]

After surgery

Both the progression of nonoperative and postoperative management of calcaneal fractures include traditional immobilization and early motion rehabilitation protocols. In fact, the traditional immobilization protocols of nonoperative and postoperative management are similar, and are thereby combined in the progression below. [30] Phases II and III of traditional and early motion rehabilitation protocols after nonoperative or postoperative care are comparable as well and are described together below. Level 1b [31][32]

1. Phase I for Traditional Immobilization and Rehabilitation following Nonoperative and Postoperative Management: Weeks 1-4
a. Goals:
- Control edema and pain
- Prevent extension of fracture or loss of surgical stabilization
- Minimize loss of function and cardiovascular endurance
b. Intervention:
- Cast with ankle in neutral and sometimes slight eversion,
- Elevation
- Ice
- After 2-4 days, instruct in non-weight bearing ambulation utilizing crutches or walker
- Instruct in wheelchair use with appropriate sitting schedule to limit time involved extremity spends in dependent-gravity position
- Instruct in comprehensive exercise and cardiovascular program utilizing upper extremities and uninvolved lower extremity

2.Phase II for Traditional Immobilization/Early Mobilization and Rehabilitation following Nonoperative and Postoperative Management: Weeks 5-8

a. Goals:
- Control remaining or residual edema and pain
- Prevent re-injury or complication of fracture by progressing weight-bearing safely
- Prevent contracture and regain motion at ankle/foot joints
- Minimize loss of function and cardiovascular endurance

b. Intervention:
- Continued elevation, icing, and compression as needed for involved lower extremity
- After 6-8 weeks, instruct in partial-weight bearing ambulation utilizing crutches or walker
- Initiate vigorous exercise and range of motion to regain and maintain motion at all joints: tibiotalar, subtalar, midtarsal, and toe joints, including active range of motion in large amounts of movement and progressive isometric or resisted exercises
- Progress and monitor comprehensive upper extremity and cardiovascular program

3.Phase III for Traditional Immobilization/Early Mobilization and Rehabilitation following Nonoperative and Postoperative Management: Weeks 9-12

a. Goals:
- Progress weight-bearing status
- Normal gait on all surfaces
- Restore full range of motion
- Restore full strength
- Allow return to previous work status

b. Intervention:
- After 9-12 weeks, instruct in normal full-weight bearing ambulation with appropriate assistive device as needed
- Progress and monitor the subtalar joint’s ability to adapt for ambulation on all surfaces, including graded and uneven surfaces
- Joint mobilization to all hypomobile joints including: tibiotalar, subtalar, midtarsal, and to toe joints
- Soft tissue mobilization to hypomobile tissues of the gastrocnemius complex, plantar fascia, or other appropriate tissues
- Progressive resisted strengthening of gastrocnemius complex through use of pulleys, weighted exercise, toe-walking ambulation, ascending/descending stairs, skipping or other plyometric exercise, pool exercises, and other climbing activites
- Work hardening program or activities to allow return to work between 13- 52 weeks

Resources

http://ezinearticles.com/?Rehabilitation-After-Calcaneal-Fractures&id=4082480
http://orthopedics.about.com/od/footanklefractures/a/calcaneus.htm
http://xnet.kp.org/socal_rehabspecialists/ptr_library/09FootRegion/31Foot-CalcanealFracture.pdf
http://www.healthstatus.com/articles/Calcaneal_Fractures.html

Clinical Bottom Line

Calcaneal fractures can be divided in two groups: intra-articular en extra-articular calcaneal fractures. Intra-articular fractures have a lower prognosis. To determine the kind of fracture and if there is a fracture, medical imagery is needed. The rehabilitation consists of 3 stages postoperatively and are very important to recover in the best way possible.

Presentations

fckLRImage:calcaneal_fracture_presentation.png|200px|border|left|fckLRrect 0 0 830 452 <a href="http://prezi.com/htzzh_lneqpu/calcaneal-fractures/">[n]</a>fckLRdesc nonefckLR <a href="http://prezi.com/htzzh_lneqpu/calcaneal-fractures/">Calcaneal Fractures</a>

This presentation, created by Alice Thompson, provides an interactive insight into presentation, causes and types of calcaneal fractures as well as the evidence base for treatment options.

<a href="http://prezi.com/htzzh_lneqpu/calcaneal-fractures/">Calcaneal Fractures/ View the presentation</a>
