Partial Knee Replacement

Original Editor - Venugopal Pawar

Top Contributors - Venugopal Pawar, Ahmed Nassef and George Prudden

Description

Pic tkr 04 big.jpg

A partial knee replacement (PKR) is a surgical procedure to replace only one part of a damaged knee. It can replace either the inside (medial) part, the outside (lateral) part, or the kneecap (Patellofemoral) part of the knee.

With PKR, only the damaged area of the knee joint is replaced, which may help to minimize trauma to healthy bone and tissue, and also helps relieve arthritis in on or two of the three compartments of the knee.

Surgery to replace the whole knee joint is called total knee replacement.

Indication

Partial Knee Replacement is intended for use in individuals with joint disease resulting from Degenerative, Rheumatoid and Post traumatic arthritis, and for moderate deformity of the Knee.

Clinical Presentation

People with advanced osteoarthritis and conservative treatments have been exhausted.[1]

Mild valgus or varus deformity.

Pain is often noted when performing physical activities requiring a wide range of motion in the knee joint.[2]

Diagnostic Tests

X-ray and MRI of the joint will reveal the joint disease resulting from Degenerative, Rheumatoid or any Post traumatic arthritis, and also moderate deformity of the Knee.

The x-ray indication for a knee replacement would be weightbearing x-rays of both knees- AP, Lateral, and 30 degrees of flexion. AP and lateral views may not show joint space narrowing, but the 30 degree flexion view is most sensitive for narrowing. If this view, however, does not show narrowing of the knee, then a knee replacement is not indicated.

Surgical Procedure & Types of Partial Knee Replacement.



Types:



PKR 3.png MEDIAL

PKR 2.pngPATELLOFEMORAL



Pkr 1.jpg  LATERAL



PKR-4.png  BICOMAPRMENTAL


  • Unicondylar Knee Replacement is a procedure that replaces only the single affected compartment of the knee, either the medial or lateral compartment.
  • Patellofemoral Knee Replacement is a procedure that replaces the worn patella (the kneecap) and the trochlea (the groove at the end of the thighbone).
  • Bicompartmental Knee Replacement is a procedure that replaces two compartments of the knee, the medial and patellofemoral compartments.

Pre-operative Preparation

Pre-operative preparation begins immediately following surgical consultation and lasts approximately one month.

The patient is to perform range of motion exercises and hip, knee and ankle strengthening (Isometrics) as directed by Therapist.

Before the surgery is performed, pre-operative tests are done: usually a complete blood count, electrolytes, APTT and PT to measure blood clotting, chest X-rays, ECG, and blood cross-matching for possible transfusion.

About a month before the surgery, the patient may be prescribed supplemental iron to boost the hemoglobin in their blood system. Accurate X-rays of the affected knee are needed to measure the size of components which will be needed. Medications such as warfarin and aspirin will be stopped some days before surgery to reduce the amount of bleeding. Patients may be admitted on the day of surgery if the pre-op work-up is done in the pre-anesthetic clinic or may come into hospital one or more days before surgery. Some hospitals offer a pre-operative seminar[3] for this surgery. Currently there is insufficient quality evidence to support the use of pre-operative physiotherapy in older adults undergoing total knee arthroplasty[4]

Preoperative education is currently an important part of patient care. There is some evidence that it may slightly reduce anxiety before knee replacement surgery, with low risk of detrimental effects.[5]

Weight loss surgery before a knee replacement does not appear to change outcomes.[6]

Post-operative Rehabilitation

The length of post-operative hospitalization is 5 days on average depending on the health status of the patient and the amount of support available outside the hospital setting.[7] Protected weight bearing on crutches or a walker is required until specified by the surgeon [8] because of weakness in the quadriceps muscle[9]

To increase the likelihood of a good outcome after surgery, multiple weeks of physical therapy is necessary. In these weeks, the therapist will help the patient return to normal activities, as well as prevent blood clots,improve circulation,increase range of motion,and eventually strengthen the surrounding muscles through specific exercises.

Week 1

Goals

  • Decrease pain/swelling.
  • Passive range of motion <90 degrees (secondary to stitches) x 2 weeks.
  • Full weight bearing.

Week 2 - 4

Goals

  • Decrease pain/swelling.
  • Tolerate bilateral stationary cycling.
  • Active range of motion 0-90 degrees.

Week 4 - 6

Goals

  • Normal gait pattern.

Week 6 - 8

Goals

  • Active range of motion 0 to 110 degrees.
  • Passive range of motion 120 degrees.

Week 8 - 12

Goals

  • Road cycling.
  • Walk downstairs with reciprocal gait.
  • Full range of motion.[10]

Treatment includes encouraging patients to move early after the surgery. [11] Often range of motion (to the limits of the prosthesis) is recovered over the first two weeks (the earlier the better). Over time, patients are able to increase the amount of weight bearing on the operated leg, and eventually are able to tolerate full weight bearing with the guidance of the physical therapist. After about ten months, the patient should be able to return to normal daily activities, although the operated leg may be significantly weaker than the non-operated leg.[12]

For knee replacement without complications, continuous passive motion (CPM) can improve recovery. [13]Additionally, CPM is inexpensive, convenient, and assists patients in therapeutic compliance. However, CPM should be used in conjunction with traditional physical therapy. In unusual cases where the person has a problem which prevents standard mobilization treatment, then CPM may be useful.


Contra-indications  & Common side-effects  Key Evidence

  • Some physicians and patients may consider having lower limbs venous ultrasonography to screen for deep vein thrombosis after knee replacement.However, this kind of screening should be done only when indicated. If a medical condition exists that could cause deep vein thrombosis, a physician can choose to treat patients with cryotherapy and intermittent pneumatic compression as a preventive measure.[14]
  • Partial Knee EReplacement surgery is not appropriate for patienst with certain types of Infections, any mental or Nueromuscular disorder which would create an unacceptable risk of prosthesis instability, prosthesis fixation failure or complication in postoperative care, skeletal immaturity, severe instability of the knee or Excessive body weight.
  • Comom side effects:as with any surgery, PKR has its risks which may be Implant related risks which may lead to a revision include dislocation, loosening, fracture, nerve damage, heterotropic ossification, wear of the implant, metal sensitivity, soft tissue imbalance, osteolysis(localized progressive bone loss) and reaction to particle debris.
  • Knee implants may not provide the same feel or performance characteristics experienced with a normal healthy joint.
